Description
| Specification parameters | Parameter details |
|---|---|
| Model Number | SC-US |
| Baud Rate | 9600 bps |
| Main Body | Weight 500 g |
| Shell Material | ASA |
| Operating Voltage | DC12~24 V |
| Working Environment | Temp. -40~70℃，relative humidity 5%~90% |
| Output Signal | RS485, Modbus protocol |
| Small-size Solar Panel | 6.5V, 4mA |
| Wind Speed | Range 0~40 m/s Accuracy ＜10 m/s, ±0.5 m/s ≥10 m/s, ±5% Resolution 0.1 m/s |
| Wind Direction | Range 0~359° Accuracy ＜2 m/s, ±10°, ≥10 m/s, ±7° Resolution 1° |
| Rainfall | Range 0~9999 mm Accuracy ±10% Resolution 0.1 mm |
| Temperature -40~60℃（-40℉~140℉） ±0.3℃（±0.6℉） 0.1℃（0.1℉） | Range -40~60℃ （-40℉~140℉） Accuracy ±0.3℃（±0.6℉） Resolution 0.1℃（0.1℉） |
| Relative Humidity | Range 1%~99% Accuracy ±3.5% Resolution 1% |
| Light Intensity | Range 0~200 KLux Accuracy ±15% Resolution 10 lux |
| UV Index | Range 1~15 Accuracy ±2 Resolution 1 |
| Barometric Pressure | Range 300 hpa ~ 1100 hpa Accuracy ±3 hpa Resolution 1 |
