Description

Model No
HT-DIM-030L
HT-DIM-030S

AC input:
230VAC
120VAC
50/60Hz Singel Phase

Input Current: 17A Max

Safety:
Anti 6KV Lightning Surge
Dim to 0%,Dry Switch-Contact

Performance: Harmonic Current Inhibition

Optimal Brightness level: 0-100%

Five Protections:
OVP (Over Voltage Protection)
UVP( Under Voltage Protection)
OPP (Over Power Protection)
OTP (Over Temperature Protection)
OCP (Over Current Protection
Short Circuit Protection

Dimensions: 293*213*105mm

Weight: 3.3kg

Permitted ambient temperature: -20℃-50℃

Storage temperature: -30℃-80℃

IP Grade: IP54

External Control: 0-10V
